3 Application of VS 300
The VS 300 Pack Controller is designed for controlling small to medium refrigeration compressor packs and
condensers. It contains its own user interface with 4-digit 7-segment LED display and is suitable for stand-alone
use. When expanded by an optional CAN bus module, it can be fully integrated into the LDSWin remote moni
toring system. Additionally, it can be combined with an optional alarm module containing two alarm relays (Prior
ity 1 and Priority 2).
For the compressor pack and condenser the VS 300 provides the following functions:
S Control and regulation
S Fault reporting
S Fault archiving
S Monitoring
S Archiving
These functions are as follows:
Pressure control with two freely configurable control loops for one or two independent refrigerant circuits (tem
perature/pressure ranges: NT - low-pressure normal-temperature refrigeration, LT - low-pressure low-tempera
ture refrigeration and HP - high pressure) Depending on the expansion stage, the maximum number of relay/
control stages is as follows:
‐ 4 relay/control stages (basic configuration)
‐ 8 relay/control stages (first expansion stage)
‐ 12 relay/control stages (second expansion stage)
The relay/control stages can be allocated to one control loop or split between the two control loops. Capacity-
controlled compressors with up to three capacity stages are supported.
S The following control types are supported:
- Step control
- Speed control
- Combined control
S Base load rotation (running sequence control)
S Load shedding
S Booster operation
S Data archiving
- Messages/alarms
- Starts
- Run times
- Activity/utilization
S Monitoring functions
