Parameter List and Menu Structure of VS 300
106
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
CL1 CL2 Function/
Description
Range Default Dim.
Displayed / Condition
(1): Minimum of one stage must
be defined in CL:
CL1: S301 > 0
CL2: S331 > 0
NT LT HP
S304.1..
S304.12
S334.11.
.
S334.12
Enable/disable relay/
control stage 1 - 12
1)
0: Disabled
1: Enabled
1 1 1 -
(1)
S305 S335 Number of disabled
relays on load shed
ding
0..3 0 0 0 -
S306 S336 Enter refrigerant For details see 3) 3 3 3 -
S308 S338 Set pressure trans
mitter parameter:
Pressure at 4 mA
0,0..2,0 0,0 0,0 1,0 bar
S309 S339 Set pressure trans
mitter parameter:
Pressure at 20 mA
8,0..60,0
10,0 10,0 26,0
bar
S310 S340 Enable temperature
shift
0: Disabled
1: Enabled
0 0 0
-
S311 S341 Enable humidity shift
0 0 0
-
S312 S342 CAN Bus node
number for ambient
data CL#
1..9 or disabled
--- --- ---
-
- S343 Enable max. tempe
rature disable CL2
0: Disabled
1: Enabled
0 0 0
-
(1) and
CL1 must be LP controller and
CL2 must be HP controller
(see S390)
S314 S344 Enable min. tempe
rature disable
CL1/CL2
1 1 -
-
Respective CL must not be HP
controller
S315 S345 Refrigeration point
control
0: Control by suction
pressure
1: Control by refrigeration
point
0 0 - -
S316 S346 Refrigeration point
CAN Node No.
1 - 99 or disabled --- --- - -
S317 S347 Forced shutdown/
Activate oil equaliza
tion function
0: Not activated
1: Activated
0 0 - -
S318 S348 Maximum run time 60...180 180 180 - min
Respective CL must not be HP
controller
Forced shutdown must be acti
vated in CL
S319 S349 Standstill time 1...5 2 2 - min
1)
Maximum values varying with expansion stage/Number of relay stages can be 4/8/12
2)
Dependent on expansion stage/number of relay stages
3)
R
efrigerant: 0=R22, 1=R502, 2=R134a, 3=R404A, 4=R402A, 5=R717, 6=R1270, 7=R507, 8=R407C,
9
=R410A, 10=R290, 11=R744, 12=R407F, 13=R422A, 14=R422D, 15=R408A, 16=R407D, 17=R407A,
18=R427A, 19=R438A, 20=R152a, 21=R170, 22=R600, 23=R600a, 24=R449A, 25=R450A, 26=R448A,
27=R455A, 28=R447B, 29=R1234ze, 30=R1233zd, 31=R1234yf
Parameter List S3: To change values set access level to setpoint adjustment enabled
(Parameter A060=1, see section 7.7 Changing the Access Level).
