Parameter List and Menu Structure of VS 300
142
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
S Menu 6-3-4 Starts
HISTORY POS: XXXXX Entry
Date: dd.mm.yy Date ↑, ↓
Starts CL1 → Next: Screen 6-3-4-a →
↓ Select date by ↑↓, max. 31 days past ↑, ↓
S Screen 6-3-4-a Starts CL1
Starts CL1 POS: XXXXX Entry
Stage 1 hh.mm Daily starts compressor/fan stage 1
1)
↑, ↓
...
Stage 12 hh.mm Daily starts compressor/fan stage 12
1)
↑, ↓
1)
Number of relay/control stages CL1 [1..n] + Number of relays CL2 [n+1..m] + Number internal alarm relais
<= Number of relay/control stages VS 300 (max. 4, 8, 12 depending on expansion stage and configuration);
see section 4.1.1 System Configuration - Allocation of Relay/Control Stages
S Menu 6-3-5 Starts Day
HISTORY POS: XXXXX Entry
Date: dd.mm.yy Date ↑, ↓
Starts CL1 D → Next: Screen 6-3-5-a →
↓ Select date by ↑↓, max. 31 days past ↑, ↓
S Screen 6-3-5-a Starts CL1 Day
Starts CL1 D POS: XXXXX Entry
Stage 1 hh.mm Daily starts compressor/fan stage 1
1)
↑, ↓
...
Stage 12 hh.mm Daily starts compressor/fan stage 12
1)
↑, ↓
1)
Number of relay/control stages CL1 [1..n] + Number of relays CL2 [n+1..m] + Number internal alarm relais
<= Number of relay/control stages VS 300 (max. 4, 8, 12 depending on expansion stage and configuration);
see section 4.1.1 System Configuration - Allocation of Relay/Control Stages
S Menu 6-3-6 Starts Night
HISTORY POS: XXXXX Entry
Date: dd.mm.yy Date ↑, ↓
Starts CL1 N → Next: Screen 6-3-6-a →
↓ Select date by ↑↓, max. 31 days past ↑, ↓
