Alarms and Messages of VS 300
155
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
Status LED
(see illustration on previous page)
Message/alarm details displayed
1 Message/alarm code: E001...E246
For details see section 8.3 Message/Alarm Types
or section 7 Parameter List and Menu Structure -
Parameter List F
2 Message/alarm status: 0: Message/alarm not active / 1: Message/alarm active
3
4
5
6
7
Receive time stamp: Day
Month
Year
Hour
Minute
8
9
10
11
12
Send time stamp: Day
Month
Year
Hour
Minute
Value shown on display identified by relay/control stage status LEDs
ZNR. 51203 51 230
E0
ESC
RESET
1 2 3 4
1 2
5 6 8
9 10 11 12
7
Status
12
OFF
//
OFF
1
2
3
4
5 6
7
8
9
10 11 12
( 1) Message/alarm code:
( 2) Message/alarm status:
( 3) Receive time stamp:
( 4) Receive time stamp:
(5)Receive time stamp:
( 6) Receive time stamp:
( 7) Receive time stamp:
( 8) Send time stamp:
( 9) Send time stamp:
(10) Send time stamp:
(11) Send time stamp:
(12) Send time stamp:
E001..E246
0: not active / 1: active
Day
Month
Year
Hour
Minute
Day
Month
Year
Hour
Minute
Items 8 - 12 are not displayed when the message/alarm status is 1 (active)!
