ECKELMANN VS 300 - 4.3 Low-Pressure Control and Compressor Management

Application of VS 300
13
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
S Control of two independent high-pressure loops (HP/HP).
HP
Regelkreis 2
ZNR. 51203 52 230 E0
HP
C
p
C
p
to NT/LT ref. point
to NT/LT ref. point
VS 300
CL 2CL 1
Controlloop 2Controlloop 1
from NT/LT ref. point from NT/LT ref. point
S Satellite operation - with common condenser
ZNR. 51203 52
430 E0
LP
NT
LP
LT
to LT ref. point
0NT
p
0LT
p
from NT ref. point
from LT ref. point
to NT ref. point
Regelkreis 2
VS 300
CL 2CL 1
Controlloop 2Controlloop 1
S Booster operation - with common condenser
Controlloop 2
ZNR. 51203 52 330 E0
VS 300
CL 2CL 1
LP
NT
Controlloop 1
LP
NT/LT
0NT
p
0NT/LT
p
from NT ref. point
to NT ref. point
from NT ref. point
to NT ref. point
The parameter list - see chapter 3 parameter list and menu structur - is to be considered for satellite
and booster operation. There in detail one describes, under which conditions these modes of opera
tion are to be adjusted. Configuration of the controller must be made prior to individual parameter
setting, because default settings will be loaded when changing the configuration.
