Function of VS 300
20
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
C - Polarity of digital input:
Integral operation
VS 300 LED display
Display
AL 300 or CI 3000
Polarity
0 Polarity 0 Function activated when input is de-energized
1 Polarity 1 Function active when input is energized
D - Alarm delay:
Integral operation
VS 300 LED display
Display
AL 300 or CI 3000
Time delay
0..60 Time delay xs Alarm delay (seconds):
If digital input is configured as alarm input, alarm will be transmitted at
end of set delay.
E - Alarm text (with CAN bus module only):
Integral operation
VS 300 LED display
Display
AL 300 or CI 3000
delay
Alarm text cannot be entered
in VS 300!
Alarm text:
xxxxxxxxxxxxxxxxxxxxxx
When the controller is fitted with the CAN bus module, a message text
can be entered for each alarm input to be displayed on the AL 300 or
CI 3000.
