A green point on the reference track defines the car position for the position indicated in the log
pane. This way, by moving along the log pane, you can see the set of parameters for particular car
positions.
The Section times pane displays times in defined sections for all laps. The best times are marked
green. Additionally, this pane has two columns: Virtual best and Rolling best. The Virtual best is
the sum of the best times in individual sections, while Rolling best shows the best continuous time
of a single lap. It is indicated by a red, vertical line and, in our example, it was scored in laps 3 and
4. This time is the feasible time that you can score.
The channels that may be helpful in analysing data:
Channel Description
adu.track.lap Displays the current lap
adu.track.lapTime Displays the current lap time
adu.track.gainLoss Displays the gain/loss relative to the best recorded lap
Adu.track.distance Current lap distance
gps.speed The vehicle speed read from the GPS
gps.status The GPS module status In case of problems with the signal, the analysed
data may be inaccurate.
ecu.rpm The engine speed
ecu.tps The throttle position
ecu.clt The coolant temperature
ecu.map The pressure in the intake manifold
ecu.oilPress The engine oil pressure
ecu.oilTemp The engine oil temperature
