1 if voltage > [V] Defines the voltage representing the value 1 for the Switch type. In order for
this condition to be fulfilled, the voltage needs to be greater than that defined
by the time from the field for [s]
0 if voltage < [V] Defines the voltage representing the value 0 for the Switch type. In order for
this condition to be fulfilled, the voltage needs to be smaller than that defined
by the time from the field for [s]
Min value for
voltage
This value defines the minimum sensor value for the defined Voltage when
using a Linear analog sensor
Max value for
voltage
This value defines the maximum sensor value for the defined Voltage when
using a Linear analog sensor
Example configurations:
A configuration for a button connected to ground and
to analogue input 1. The value a_sampleButton will
be 0 when the button is not pressed and 1 when it is.
Configuration for a pressure sensor in the intake
manifold (MAP) connected to analogue input 2. The
value a_mapSensor115kPa will assume values
ranging from 10.0kPa to 115.0kPa
Page 78/137
