Titanium Interfaces User Guide
Table 78: Lane Mapping Tab
Parameter Choices Notes
Phy Lane n clk, data0, data1,
data2, data3, unused
The MIPI TX block supports 4 data lanes and 1 clock
lane. Choose which lane to associate with the MIPI pad.
The lane mapping must be unique, which the software
enforces.
Swap P&N Pin On or off Turn on to change which pin is P or N. This setting can be
helpful when laying out your board.
www.efinixinc.com 120
