Titanium Interfaces User Guide
Chapter 1
Get Oriented
Contents:
• Interface Blocks
• Package/Interface Support Matrix
• Interface Block Connectivity
• Designing an Interface
• Create or Delete a Block
• Using the Resource Assigner
• Interface Designer Output Files
• Scripting an Interface Design
The Interface Designer has four main sections:
• Design Explorer—Provides a list view of the interface blocks you have in your design
organized by block type. It also includes device-wide settings for the I/O banks and
configuration options. Select a block to display it's summary and editor.
• Block Summary—Displays the current settings for the selected block.
• Block Editor—Provides options and settings for the selected block. The editor may have
more than one tab, depending on the block.
• Resource Assigner—Provides an easy, tabular method for assigning resources. View by
instance (default) or resource.
