Titanium Interfaces User Guide
Table 25: AXI 0 and AXI 1 Tabs
Parameter Choices Notes
Enable Target 0
Enable Target 1
On or off Turn on to enable the AXI 0 interface.
Turn on to enable the AXI 1 interface.
Enable 256-bit AXI Width 256, 512 Choose the AXI bit width. Default: 512
AXI Clock Input Pin Name User defined Specify the name of the AXI input clock pin.
Invert AXI Clock Input On or off Turn on to invert the AXI clock.
AXI Reset Pin Name User defined Specify the name of the AXI reset clock pin
or use the default.
Read Address Channel tab
Write Address Channel tab
Write Response Channel tab
Read Data Channel tab
Write Data Channel tab
User defined These tabs defines the AXI signal names for
the channels. Efinix recommends that you
use the default names.
