Titanium Interfaces User Guide
gpio_rule_input_mode (error)
Message For input mode, input must be configured
To fix You need to configure the input parameters.
Message For input mode, input pin name must be configured
To fix Specify a name for the input pin.
Message Input pin name with square bracket does not match a bus name with index
To fix You probably used a bracket [ or ] in the pin name. Rename the pin without brackets.
gpio_rule_input_register (error)
Message Input clock pin name is empty
Input clock pin name has illegal character
To fix If you are using the register option, you need to specify a valid clock pin name.
gpio_rule_input_register (warning)
Message Input clock pin name is empty
Input clock pin name has illegal character
To fix If you have a GPIO block in inout mode, you get this message if you do not specify an input
pin name or if you use invalid characgters in the name. You should specify a name to use the
pin as bidirectional.
Message Alternate input connection cannot be registered
To fix When you are using an alternate connection type. you cannot use the register. Set Register
Option to none.
gpio_rule_output_mode (error)
Message For output mode, output must be configured
To fix You need to configure the output parameters.
Message For output mode without constant output, output pin name must be configured
To fix For GPIO output blocks, you can drive them as 0 or a 1 with the Constant Output option. In
that mode, you do not need to specify an output pin name. If you are using Constant Output
set to none (as you would for a regular output pin), you need to specify a pin name.
Message Output pin name with square bracket does not match a bus name with index
To fix You probably used a bracket [ or ] in the pin name. Rename the pin without brackets.
www.efinixinc.com 57
