Titanium Interfaces User Guide
Option Values Notes
Active-Low HyperRAM Reset Pin Name User defined
Active-Low HyperRAM Chip Select Pin Name User defined
Differential Clock Pin Name (P HI) User defined
Differential Clock Pin Name (P LO) User defined
Differential Clock Pin Name (N HI) User defined
Differential Clock Pin Name (N LO) User defined
Read/Write Data Strobe Output [1:0] Bus Name
(HI)
User defined
Read/Write Data Strobe Output [1:0] Bus Name
(LO)
User defined
Read/Write Data Strobe Output Enable [1:0] Bus
Name
User defined
Read/Write Data Strobe Input [1:0] Bus Name
(HI)
User defined
Read/Write Data Strobe Input [1:0] Bus Name
(LO)
User defined
DQ Output [15:0] Bus Name (HI) User defined
DQ Output [15:0] Bus Name (LO) User defined
DQ Output Enable [15:0] Bus Name User defined
DQ Input [15:0] Bus Name (HI) User defined
DQ Input [15:0] Bus Name (LO) User defined
