Analyzer User Guide
The Field tab appears:
Name boxes are synchronized to the selected event in the
, which is synchronized to the Details pane. The Value boxes reflect
data elements displayed in the
Details pane. Users may type strings (values,
wildcards, or ranges) directly into the Value boxes.
2. Select one or more items from the Name boxes.
3. Select corresponding items from the Value boxes.
4. Select the desired match type in the Find items that drop-down menu.
5. Click on Find Next.
The next event matching the search criteria is highlighted in the Overview.
To display a count of matching criteria:
1. Define the search criteria from the Payload, Text, and/or Field tabs.
2. Select the desired match type in the Find items that drop-down menu.
3. Select the drop-down arrow
at the bottom-right of the Search dialog.
4. Select Count.
The Find Next button changes to a Count button.
5. Click on the Count button.
92 of 201 | Overview Windows
