Submenu Function
HDBaseT
Control Communications: (This cannot be set when
Extron XTP is set to On.) When set to On, Ethernet
communication, serial communication, and the wired
remote control through the HDBaseT Transmitter connected
to the HDBaseT port are all enabled.
Extron XTP: Set to On when you connect the Extron XTP
transmitter or switcher to the HDBaseT port. See the
following Extron Web site for more details on the XTP
system.
http://www.extron.com/
a
• When Control Communications or Ex‐
tron XTP is set to On, Standby Mode is
automatically set to Communication On.
• When Control Communications or Ex‐
tron XTP is On, the projector's LAN
port, RS-232 port, and Remote port are
disabled.
• When Extron XTP is set to On, the fan
may rotate in standby mode but this is
not abnormal.
Color Calibra-
tion
Start Auto Adjustment: Automatically adjusts the color
tone for the whole screen.
s "Color Calibration" p.214
Undo: Undoes the auto adjustment.
Redo: Redoes the auto adjustment.
Color Uniformity: Adjusts the color tone balance for the
whole screen.
s "Color Uniformity" p.217
Reset: You can reset all adjustment values for Color
Calibration to their default values.
Submenu Function
Multi-Projection
Make settings when projecting from multiple projectors.
s "Multi-Projection Function" p.94
Projector ID: Set the ID from 01 to 30. Off indicates that
no ID is set.
s "ID Settings" p.44
Projector Grouping: When using multiple projectors to
project one image, select the projectors being used.
Tiling: Set the number of split screens and positions of each
projected image.
s
"Tiling" p.95
Geometry Correction: Corrects distortion in the projected
image.
s "Correcting Distortion in the Projected Image" p.66
Edge Blending: Corrects a border between multiple images
to create a seamless screen.
s "Edge Blending" p.98
Black Level: Adjusts the differences in brightness and tone
for areas where images overlap and areas where the images
do not overlap.
s "Black Level" p.100
Scale: When using multiple projectors to project one image,
adjust the range of the image displayed by each projector.
s "Displaying a Scaled Image" p.106
Screen Matching: Adjusts the tint and brightness for each
projector.
s "Screen Matching" p.103
Reset: You can reset all adjustment values for the Multi-
Projection menu to their default settings.
Schedule Set-
tings
You can set the projector's schedule so that it performs a
specific operation at a pre-scheduled time.
s "Scheduling Function" p.117
Language
You can set the language for messages and menus.
List of Functions
155
