Epson EB-L1505UH User Manual

ELPLL08/ELPLL07
Unit: cm
4:3 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
60" 122x91 756 to 1069 -101 to +9
80" 163x122 1019 to 1436 -134 to +12
100" 203x152 1281 to 1803 -168 to +15
120" 244x183 1544 to 2170 -201 to +18
150" 305x229 1937 to 2720 -252 to +23
200" 406x305 2594 to 3637 -335 to +31
250" 508x381 3250 to 4555 -419 to +38
500" 1016x762 6351 to 9141 -839 to +77
800" 1626x1219 10469 to 14645 -1342 to +123
Unit: cm
16:9 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
60" 133x75 683 to 968 -87 to +13
80" 177x100 922 to 1301 -116 to +17
100" 221x125 1160 to 1634 -145 to +21
120" 266x149 1398 to 1967 -174 to +25
150" 332x187 1756 to 2467 -218 to +31
200" 443x249 2352 to 3300 -291 to +42
250" 553x311 2948 to 4132 -363 to +52
500" 1107x623 5927 to 8296 -727 to +104
800" 1771x996 9502 to 13293 -1163 to +167
Unit: cm
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
60" 130x81 664 to 941 -89 to +8
80" 172x108 896 to 1265 -119 to +11
100" 215x135 1128 to 1589 -148 to +14
120" 258x162 1360 to 1913 -178 to +16
150" 323x202 1708 to 2399 -222 to +20
200" 431x269 2287 to 3209 -296 to +27
250" 538x337 2867 to 4020 -370 to +34
500" 1077x673 5765 to 8071 -741 to +68
800" 1723x1077 9244 to 12933 -1185 to +108
1000" 2154x1346 11562 to 16174 -1482 to +135
ELPLR04
Lens shift is not supported.
Unit: cm
4:3 Screen Size
AB
60" 122x91 99 -46
80" 163x122 134 -61
100" 203x152 169 -76
120" 244x183 205 -91
150" 305x229 257 -114
200" 406x305 345 -152
250" 508x381 433 -191
500" 1016x762 874 -381
Screen Size and Projection Distance
251
