(2) Adjust the lens shift.
s "Adjusting the Position of the Projected Image (Lens Shift)" p.34
(3) Adjust the zoom and focus.
s "Adjusting the Image Size" p.38
s "Correcting the Focus" p.39
(4) Adjust small differences in the images.
s "Point Correction" p.76
(5) Adjust the edges of the images.
s "Edge Blending" p.98
s "Black Level" p.100
(6) Adjust the brightness and tint of the images.
s "Screen Matching" p.103
(7) Select the sections of the images.
s "Displaying a Scaled Image" p.106
Adjusting manually offline
Adjust the images from all projectors manually.
Advance preparation
(1) Turn on all projectors.
(2) Set an ID for all projectors and the remote controls.
s "Set the projector ID" p.44
Adjusting the projected position
(1) Adjust the position (angle) of the projector.
s "Installation Settings" p.30
(2) Adjust the arrangement of the images.
s "Performing tiling manually" p.97
Adjusting the projected images
s
"Adjusting the projected images" p.94
Tiling
Project the same image from multiple projectors to create one large image.
You can project by using up to nine projectors.
a
Before performing tiling, adjust the projected image so that it is a
rectangle. Also, adjust the size and focus of the images.
s
"Adjusting the Image Size" p.38
s "Correcting the Focus" p.39
Performing tiling automatically
This section explains how to select the projector being used in Projector
Grouping, and then automatically configure the images being projected.
a
Location setup is performed using the camera built into the front of
the projector. Do not block the camera or the projected images.
Multi-Projection Function
95
To Next Page
