Installing
the
Wireless
LAN
Unit
a
Remove
the
air
filter
cover.
Grip
the
air
filter
cover
tab
between
your
fingers,
and
pull
up
and
r
e
m
o
v
e t
h
e c
o
v
e
r w
h
i
l
e
p
r
e
s
s
i
n
g t
h
e t
a
b
.
b
R
e
m
o
v
e t
h
e s
t
o
p
p
e
r f
o
r t
h
e W
i
r
e
l
e
s
s L
A
N u
n
i
t
.
c
Install
the
Wireless
LAN
unit.
d
Secure
the
st
opper
with
a
screw.
e
Attach
the
air
filter
cover.
