Art-Net
Art-Net is an Ethernet communication protocol based on the TCP/IP protocol.
You can control the projector by using a DMX controller or an application system.
Channel definitions
The following explains the channel definitions used when controlling the projector in Art-Net.
Chan-
nel
Function Operation Parameters Default Operation Content
1 Adjusting light (Dimming) 0% - 100% 0 - 255 0 Sets the image brightness.
2 Shutter control Shutter Open 0 - 63 128 Enables/disables A/V Mute.
Non-operational 64 - 191
Shutter Closed 192 - 255
3 Switch source Non-operational 0 - 7 0 Changes to the specified source.
HDMI 8 - 15
Non-operational 16 - 23
HDBaseT 24 - 31
DVI-D 32 - 39
Non-operational 40 - 47
SDI 48 - 55
Computer 56 - 63
Non-operational 64 - 71
BNC 72 - 79
LAN 80 - 87
Non-operational 88 - 95
Non-operational 96 - 255
Monitoring and Controlling
237
