Epson EB-L1505UH User Manual

4:3 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
500" 1016x762 5612 to 7865 -800 to +38
800" 1626x1219 8999 to 12603 -1280 to +61
1000" 2032x1524 11256 to 15762 -1600 to +76
Unit: cm
16:9 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
60" 133x75 705 to 1001 -92 to +17
80" 177x100 951 to 1345 -123 to +23
100" 221x125 1197 to 1689 -154 to +29
120" 266x149 1443 to 2033 -184 to +35
150" 332x187 1812 to 2549 -230 to +44
180" 398x224 2181 to 3065 -276 to +52
200" 443x249 2427 to 3409 -307 to +58
300" 664x374 3657 to 5130 -461 to +87
450" 996x560 5502 to 7711 -691 to +131
500" 1107x623 6117 to 8572 -768 to +145
800" 1771x996 9807 to 13734 -1229 to +233
Unit: cm
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
60" 129x81 685 to 973 -94 to +13
80" 172x108 925 to 1307 -125 to +17
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Bottom to Top
100" 215x135 1164 to 1642 -156 to +22
120" 258x162 1403 to 1977 -187 to +26
150" 323x202 1762 to 2479 -234 to +32
180" 388x242 2121 to 2982 -281 to +39
200" 431x269 2361 to 3316 -312 to +43
300" 646x404 3557 to 4991 -469 to +65
500" 1077x673 5951 to 8339 -781 to +108
800" 1723x1077 9541 to 13361 -1249 to +172
ELPLR04
Unit: cm
4:3 Screen Size
AB
60" 122x91 84 -46
80" 163x122 115 -61
100" 203x152 145 -76
120" 244x183 175 -91
150" 305x229 221 -114
180" 366x274 266 -137
200" 406x305 296 -152
300" 610x457 448 -229
500" 1016x762 751 -381
800" 1626x1219 1206 -610
1000" 2032x1524 1509 -762
Screen Size and Projection Distance
