Indicator Cause Remedy or Status

Power

supply

Status Laser Temp Filter

Blue -

Flashing

Status

varies

Orange -

Flashing

Status

varies

Status

varies

Laser Warning Stop using the projector, remove the power plug from the electrical outlet, and contact your local dealer or

the nearest address provided in the Epson Projector Contact List.

s Epson Projector Contact List

Reading the Indicators

183
