Name Function
A
[ ] button
Turns the projector on.
B
[t] button
Turns the projector off.
C
Change input buttons
Changes to images from each input port.
s "Switching to the Target Image by Remote Control"
p.64
The [SDI] button only functions for EB-L1755U/EB-
L1750U/EB-L1505UH/EB-L1500UH/EB-L1495U/EB-
L1490U.
D
[Aspect] button
Each time the button is pressed, the aspect mode changes.
s "Changing the Aspect Ratio of the Projected Image"
p.82
E
[Auto] button
If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
F
[Freeze] button
Images are paused or unpaused.
s "Freezing the Image (Freeze)" p.112
G
[Test Pattern] button
Displays a test pattern.
s "Displaying a Test Pattern" p.33
H
[Lens Shift] button
Press to adjust the lens shift.
s "Adjusting the Position of the Projected Image (Lens
Shift)" p.34
If pressed for more than three seconds, the lens position
moves to the home position.
I
[Zoom] button
Press to adjust the zoom.
s "Adjusting the Image Size" p.38
J
[Menu] button
Displays and closes the Configuration menu.
s "Using the Configuration Menu" p.141
Name Function
K
[ ][ ][ ][ ]
buttons
• Press to adjust focus, zoom, distortion, and lens shift.
s "Adjusting the Position of the Projected Image
(Lens Shift)" p.34
s "Adjusting the Image Size" p.38
s "Correcting the Focus" p.39
• When the Configuration menu or the Help screen is
displayed, pressing these buttons selects menu items
and setting values.
s "Using the Configuration Menu" p.141
• When using the optional wireless mouse receiver,
pressing these buttons moves the pointer.
L
[ ] button
• When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
s "Using the Configuration Menu" p.141
• Acts as a mouse's left button when using the optional
wireless mouse receiver.
M
[A/V Mute] button
Turns the video and audio on or off.
s "Hiding the Image and Sound Temporarily (A/V
Mute)" p.111
N
[Page] buttons
[[][]]
• Press to change the test pattern while a test pattern is
displayed.
• Moves to the previous or next image file when
projecting images from a computer connected via a
network.
• When using the optional wireless mouse receiver, you
can change the PowerPoint file page during projection
by pressing the page up/page down buttons.
O
[Volume] buttons
[a][b]
[a] Decreases the volume.
[b] Increases the volume.
s "Adjusting the Volume" p.65
P
[ ] button
Displays the Info menu from the Configuration menu.
s "Info Menu (Display Only)" p.166
Part Names and Functions
22
