Paper feed direction
Print area of Media Defini
tion to be specified in the printer driver
Label area
Backing paper
Black mark position (back side)
70.0 mm (Backing paper width)
60.0 mm (label width)
66.0 mm (label width including waste)
63.0 mm (print area width)
1.5 mm
1.5 mm
2.0 mm
1.5 mm
1.5 mm
2.0 mm
35.0 mm
(label height)
38.0 mm
(Print area height = black mark interval)
1.5 mm
1.5 mm
1.5 mm
Area to place print data
(Top: Rectangle of 63.0 x 38.0 mm/Bottom: Oval of 63.0 x 38.0 mm)
