Rev. A Disassembly, Assembly, and Adjustments 5-51
TM-U950/U950P Technical Manual
Main Assembly 1-11: Attachment of Wiring Board Assembly
1. Attach the wiring board assembly to the rear of the printer mechanism assembly and secure
it with the screw.
Printer mechanism assembly (rear)
Wiring board assembly
CONFIDENTIAL
To Next Page
