Epson TM-U950 Technical Manual

Rev. A Features and General Specifications 1-19
TM-U950/U950P Technical Manual
Notes
❏
Use a shielded cable for the drawer connection.
❏
It is not possible to drive two drawers at the same time.
❏
Use a solenoid rated for at least 24
Ω
as the drawer kick-out solenoid. Otherwise, excessive current
may damage the solenoid.
❏
The drawer must be powered from the printer (connector pin 4).
❏
Do not drive the drawer continuously.
Customer display connector (not supported on the TM-U950P)
This connector is for Epson customer display (DM-D series). Do not connect other customer
displays.
Connector type: Receptacle 52065-8845 (Molex) or equivalent
Interface
Serial interface
Data transfer principle Serial (RS-232 interface)
Synchronization Asynchronous
Handshake (*) DTR/DSR or XON/XOFF
Signal level
MARK: -3 to -15 V (logical “1”/OFF)
SPACE: +3 to +15 V (logical “0”/ON)
(Voltage measured at connector, referenced to SG)
Baud rate (*) 1200, 2400, 4800, 9600 bps
Word length (*) 7 or 8 bit
Table 1-6. Customer Display Connector Pin Assignment
Pin number Signal name I/O
1Frame ground—
2NC —
3TXD O
4DTR O
5DSRI
6 Signal ground —
7 +24V DC —
8 Power ground —
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
