6 Setup 97
{MSC Transmit}
This touchbutton toggles the setting for transmitting MIDI Show Control data between “Enabled”
and “Disabled”. The default setting is “Disabled”.
{MSC Transmit Channel}
Also know as "Device ID" this setting allows you to establish the device ID with which Eos will
transmit MIDI show control information. A device ID can be from 0-126 or 127 (All Call). For
example:
• {MSC Transmit Channel} [5] [0] [Enter]
{ACN - MIDI Tx ID}
This setting allows you to specify the ID number of MIDI Show Control data that Eos transmits over
an Advanced Control Network (ACN). When set, Eos will transmit MSC data to any gateway that
has its “MIDI Out Stream ID” set to the same number. ACN_MIDI Transmit ID can be from 1-32. ID
ranges may be used.
• {ACN_MIDI Transmit ID} [2] [5] [Enter]
{Analog Inputs}
This touchbutton toggles the setting for receiving analog inputs between “Enabled” and “Disabled”.
Default is “Enabled”.
{Relay Outputs}
This touchbutton toggles the setting for allowing Eos to trigger external relays. Options are
“Enabled” or “Disabled”. The default is “Enabled”.
{Serial Enable}
This touchbutton toggles the ability to receive serial commands. Options are “Enabled” or
“Disabled”. The default is “Enabled”.
{Serial Group Ids}
This touchbutton is for setting up which serial group IDs the Eos will listen to. Serial Group IDs are
from 1-32. Eos can be set to listen to multiple group IDs.
• {Serial Group Ids} [1] [+] [5] [Enter]
Partitions
Pressing the {Partitions} button in Show setup opens the partition display in the CIA. This display
shows any recorded partitions, including the four pre-existing partitions. For more information, see
Using Partitioned Control, page 307.
Note: Filter setup and encoder configuration settings will all be available in a future
release.
