3 System Basics 49

Split Playback Status Display

Pressing [Format] with the playback status display active will access this format. With the playback

status display split, two different cue lists can be displayed at the same time by locking. If both cue

lists are unlocked, they will display the same list.

Optional

Command Line

Locked cue list

Unlocked cue list
