Test Setup - Test Configurator, Timer, and System
Power Blazer 131
Modify Structure Button
For Ethernet Test Applications
Note: For Dual Port topology each port is configurable individually.
 Interface/Rate choices depend on the selected test and the rates
available on the module. For Dual Port, both ports must be either 10GE
and less, 25GE, or 40/100GE.
Test Interface/Rate
EtherSAM
RFC 2544
RFC 6349
EtherBERT
Traffic Gen & Mon
Smart Loopback
400GE (8 Lanes) [425 Gbit/s]
a
400GE (4 Lanes) [425 Gbit/s]
a
200GE (4 Lanes) [212.5 Gbit/s]
a
100GE (4 Lanes) [103.125 Gbit/s]
40GE (4 Lanes) [41.25 Gbit/s]
25GE
b
10GE WAN
c
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
d
a. Only available for RFC 2544, EtherBERT, and Smart Loopback.
b. Only available for RFC 2544, EtherBERT, Traffic Gen & Mon, and Smart Loopback.
c. Not available with RFC 6349 test application.
d. Used as a second port when the test application requires two ports; Ethernet 10/100/1000 Mbit/s
electrical is supported when using an active copper SFP.
FlexE BERT 100GE (4 Lanes) [103.125 Gbit/s]
Carrier Ethernet OAM 10GE WAN
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
Through Mode 100GE (4 Lanes) [103.125 Gbit/s]
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
e
e. Ethernet 10/100/1000 Mbit/s electrical is supported when using an active copper SFP and the RJ45 port.
TCP Throughput 1GE Optical
100M Optical
10/100/1000M Electrical
Cable Test 10/100/1000M Electrical
