Test Results
Power Blazer 391
Alarms/Errors Overview
Alarms/Errors
From the Test menu, tap Results, and the Alarms/Errors tab. Depending
on the test structure, the Alarms/Errors page may be split in different tabs
such as OTN, GFP-T/GFP-F, PHY, Group, Client, and Ethernet; tap on the
desired tab when required.
Alarms/errors blocks containing the magnifier (+) icon in its title, opens a
zoomed view giving more details like alarms/errors for each lane (parallel
interface), errors in seconds, count, and rate.
When there is not enough room on the page to display the error in
seconds, count, and rate, the error is displayed in Seconds per default. To
select another unit, tap on the unit’s button and select either Seconds
(default), Count, or Rate.
Total, available with certain errors (parallel interface), indicates the total of
all lanes when Count or Rate unit is selected.
The following table lists the availability of alarms/errors per layer for
TX and RX.
Layer
Alarms/Errors
Page
TX/RX RX only
BER Pattern Loss No Traffic, Client Frequency 396
Bit Error, Pattern Error Mismatch ‘0’, Mismatch ‘1’,
Frame Loss, Out-of-Seq.
CLOCK - LOC, LOPPS-L, LOPPS-R 397
CPRI LOF, R-LOS, R-LOF, RAI, SDI Link Down 398
FAS -
DS1 AIS. OOF, RAI -399
CRC-6, Framing Bit -
DS3 AIS, Idle, OOF, RDI -400
CP-BIT, FEBE, F-Bit, P-Bit -
E1 AIS, LOF, RAI, LOMF, RAI MF, TS16 AIS -401
FAS CRC-4, E-Bit
