2. Project management
2−17
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
Individual objects in the positioning project are represented
in the project window by the following icons:
Project
All components in the positioning system are under the
Project icon.
Hardware
All hardware elements of the project  SPC200, axes,
I/Omodules  are managed under Hardware".
SPC200−CPU−4 or ...−CPU−6
... stands for an SPC200 with 4 or
6 slots.
1. Axis interface string or 2. Axis interface string
... stands for an axis interface string
Stepping motor interface
X − axis : ... (Y.. , Z.. U..)
... stands for a positioning axis. The axes of a system are
identified as X− Y−, Z− and U−axes. This is followed by the
axis
designation, usually the type.
SPC−FIO−2E/2A or CP...
... stands for an I/O function module, a CP input module or a
CP valve terminal. The designation corresponds to the type
designation of the relevant module.
Software
The position list and the positioning programs of the project
are managed under Software".
Position list
... stands for
the position list of the project.
1 : DIN NAME"
... stands for the program with program number 1. Below this
is displayed the name you have given the program.
