3. Project planning
3−4
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
3.1 Project planning of axes
WinPISA offers support in the selection of suitable cylinder−
valve combinations for pneumatic axes or linear axis−motor
combinations for electric axes.
For this purpose, WinPISA includes files with the file exten
sion *.PTA". These files contain planned specifications of the
axis parameters and application parameters for the axis sys
tems supported by the SPC200.
Providing you have the project planning tool (PtTool) from
Festo, you can save the axis plannings created therein in your
own PTA files and use them in WinPISA.
Alternatively you can also transfer the planned axes in the
PtTool via the clipboard in WinPISA (see section 4.2).
