Festo SPC200 - Recording Measurement Values

6. Diagnostics and optimization
6−33
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
6.5.2 Recording measurement values
WinPISA offers the facility for recording measurement values
for positioning processes in Debug mode. The recorded
measurement values allow you to make an exact assessment
of the positioning behaviour of the positioning system.
Please note
During the Debugmode WinPISA takes over the sequence
control of the SPC200.
This results in a different run time performance of the
program sequence.
Measurement values can only be recorded for the pneumatic
axes.
Configuring the measurement
When configuring the recording of the measured value, you
must set the type of measurement. To
do this, select the de
sired measured variables for the individual axes as well as the
scanning time for the measurement.
Configure the measurement as follows:
1. Select the command [Configure] in the menu [Online]
[Measurement].
2. Select the axes, for which measurements are to be made
under Activate for axes" in the dialogue window Confi
gure
measurement".
3. All available measured variables will be shown under
Measurable data". The settings for the possible axes X,
Y, Z and U will each be shown on a tab card under Con
figuration for axis".
