6. Diagnostics and optimization
6−44
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
6.6.3 Graphic elements
All graphic windows in WinPISA follow the same layout and
consist of the following elements:
12 3 4
5
6
7
89aJ
1 Display area
2 Graphic title
3 Co−ordinate display
4 Legend
5 Curve 1
6 Curve 2
7 Further curves
8 X axis (abscissa axis)
9 y1 axis (first ordinate axis)
aJ y2 axis (second ordinate axis)
Fig.6/21: Graphic window
