5.1 Program administration
The project window provides an environment for easy man
agement of user programs.
All programs and the position list are allocated to the Soft
ware" area; you will therefore find these under the software
icon of the project window.
You can use up to 100 programs in programming for the
SPC200, using program numbers
0 to 99. You can describe
the task or function of a program using a name and a com
ment for easier orientation.
A position list is a fixed component of each project. It cannot
therefore be deleted or created.
Creating a new program
You create a new program when you want to
specify a new
positioning task.
To create a new program:
1. Select the software icon in the project window by clicking
on it or moving the highlight to the icon using the ARROW
KEYS.
2. Select [Insert object] from the [Edit] menu or press the
INSERT key.
3. Enter a program title in the Title" field, enter a
short
description in the Description" field, and enter the
program number required in the Program no." field in
the Newprogram" dialogue window.
4. Click OK" to confirm your entry. The new program
appears in the project window. The program window is
opened.
