Festo SPC200 - Setting Axis−Specific Parameters

4. Commissioning positioning systems
4−20
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
4.3 Setting axis−specific parameters
Set the specific parameters for the axes of the positioning
system. These include:
Parameter
Description
Axis parameters Structure, characteristics and
components of the axis used
Application parameters Conditions of use specified by the
application
Controller parameters Settings which affect the control
ling behaviour of the axis
Nominal value input Settings for the reaction of the
nominal value specification
If you select the *.PTA file when inserting the axis, you accept
the default values for the valve−cylinder combi−nation of your
axis. You then simply have to adapt these values to your par
ticular case.
The specifications of the project−specific parameters for an
axis have a direct effect on determining the control−ler para
meters,
and thus on the quality of positioning.
If the hardware configuration of the SPC200 corresponds to
the project, you can load the configured values of the current
tab card into the SPC200 in active Online mode in the dia
logue window Parameter set for the .. −axis".
Take note of the warning message
displayed when you are
downloading the settings and acknowledge with Continue".
