4.3.1 Axis parameters
The axis parameters are configuration parameters which de
scribe the installation, characteristics and components of the
axis used. The axis parameters form the basis for parameter
ranges in application parameters (e.g. possible axis move
ment speeds).
Set the axis parameters on the Axis parameters" tab of the
Parameter set for the .. −axis" dialogue
window.
Please note
Modified axis data do not become effective until after a
program reset. During a download of axis data, WinPISA
automatically carries out a program reset (control signal
required: 1−signal at ENABLE).
If the axis parameters are modified, the identification data will
be reset.
Description of parameters under Axis parameters"
(pneumatic axis)
The parameters
for electric axes can be found in the relevant
manual (see section Documentation on positioning").
Cylinder designation The designation of the drive used. When axis specifications
are inserted, the designation is taken from the *.PTA file. You
can overwrite the individual entry.
Cylinder type The type of the drive. Select here the type of cylinder
from the
list:
 without piston rod
 with piston rod
 rotary (rotary drive/swivel module).
