6. Diagnostics and optimization
6−6
Festo P.BE−SPC200−WIN−PISA−CD−EN en 0901d
6.2 Status display
WinPISA’s status display provides a clear representation of
the most important system data.
The tabs in the Status display" dialogue window contain
information on:
the axis selected
the controller of the axis selected (only pneumatic axes)
the current error message as well as the contents of the
error stack
the status of the SPC200 connected
(system)
the status of the field bus connection (only if there is a
field bus module; information on this can be found in the
manual for the relevant field bus module)
effective setpoint values for speed, acceleration and de
celeration.
To open the Status display" window:
1. Select [Onlinemode] from the [Online] menu or click
on
the Online mode on" button in the toolbar to activate
Onlinemode.
2. Select [Status display] from the [Online] [Diagnosis] menu.
The window Status display" will open with the appropriate
tabs.
