Elements of the online status display
Axis−specific status displays "X:", "Y:", "Z:", "U:"
red Reference absent
green Reference is valid
grey No referencing required
yellow Warning: static identification missing
green Static identification run
grey No static identification (stepper motor)
red Warning: dynamic identification absent
green Dynamic identification run
grey No dynamic identification required (stepper motor)
The display is refreshed at intervals of about 0.1 ... 0.2 s. The
display is not refreshed during a download operation.
