User Manual LTU Orion 3
109
Speed : AUTO AUTO AUTO AUTO AUTO
Flow control : OFF OFF OFF OFF OFF
System settings
IP address : 192.168.1.6 MAC address : 00:0f:d9:04:a7:25
Subnet mask : 255.255.255.0 Management MTU : 1500
Default gateway : 192.168.1.254 WAN idle pattern: All 1's
SNMP
SNMP versions : v1 v2c v3
Allowed pollers : All
Trap IP/version : 192.168.169.12(v3, RO)
SNMP v1,v2c community
GET/SET/TRAP : public/public/public
SET command : Enabled
SNMP v3 users : Read-only (RO) Read-write (RW)
Security name : snmp_ro snmp_rw
Auth/Priv : none/none not selected
Auth Password : --- ---
Priv Password : --- ---
Services : TELNET, SSH(22), HTTP
Syslog servers :
SNTP servers : 192.168.1.254 TZ: UTC+01:00
Summer time : MAR lastSUN (30) 00:00w +60min
Winter time : OCT lastSUN (26) 00:00w +0min
Radius servers : 192.168.1.252:1812 192.168.1.254:1812
Radius secret : entered entered
--------------------------------------------------------------------------------
CO_06_NET>
VLAN (VLANs & QoS) configurations
Ethernet settings
Port identifier of the internal Ethernet switch
Description
Port Description (ifAlias)
Mode
Type of port (trunk, access or mixed)
Port based VLAN
Isolation of ports
VLAN
VLAN identifier for each of access ports
QoS
Priority for each of access ports
VLAN1 VID=xx
:
:
VLAN8 VID=xx
Configurations and identifiers (xx=1..4094) for each of 8 VLANs which are
configured separately.
Pluses and minuses mark transmission/locking of VLAN for each of
interfaces.
OTHER VLANS
Configurations for other VLANs, which are not configured separately.
Pluses and minuses mark transmission/locking for each of interfaces.
Ethernet port configurations
Speed/Duplex
Operation mode of the Ethernet interface
Flow control
Flow control mode of the Ethernet interface
General settings
MAC address
MAC address of the device
IP address
IP address of the device
Subnet Mask
Network mask of the device
Default Gateway
Default gateway of the device
Management MTU
Maximal size of management packets, bytes
WAN idle pattern
Idle pattern for empty frames if transmitted over E1 links: all 1's or 7E
SNMP settings
SNMP Version
Active SNMP versions
Allowed pollers
List of hosts allowed to perform SNMP poll
Trap IP/version
IP address of Trap receiver and Trap version. If SNMP v3 is selected, it is
shown what user (RO or RW) will send trap messages.
GET/SET/TRAP
SNMP v1 and v2c community for GET, SET and TRAP messages
SET command
Enabled or Blocked SNMP V1 and V2c SET operation
SNMP v3 users
User with Read-Only (RO) and Read-Write (RW) access rights
Security name
User names for RO and RW user
Auth/Priv
User Authentication (MD5/SHA/NONE) and Privacy (DES/AES/NONE)
Auth password
Authentication password (SNMP v3)
Priv password
Privacy password (SNMP v3)
Service settings
