User Manual LTU Orion 3
95
Presentation of CONFIG table in “independent channels with reservation” mode. In this
configuration, channels 1, 2 and 3, 4 are combined for reservation (CO, CP, CX).
CO_09_CM>CONFIG
--------------------------------------------------------------------------
Running Line Configuration
--------------------------------------------------------------------------
SHDSL DSL1 DSL2 DSL3 DSL4
Mode : Master(HTU-C) Master(HTU-C) Master(HTU-R) Master(HTU-C)
Extended rates: OFF OFF OFF OFF
Line coding : PAM32 PAM32 PAM32 PAM32
Annex : A/B A/B A/B A/B
Payload : E1-1,WAN E1-2,WAN E1-3,WAN E1-4,WAN
Clock source : E1-1,Int E1-2,Int E1-3,Int E1-4,Int
Reserve : {==== Reserve group A ====} {==== Reserve group B ====}
Power : OFF OFF OFF OFF
GS compatible : OFF
E1 E1-1 E1-2 E1-3 E1-4
G.704 framing : OFF OFF OFF OFF
CRC4 : N/A N/A N/A N/A
AIS Detection : ON ON ON ON
AIS Generation: ON ON ON ON
E1 clock : DSL DSL DSL DSL
TS into DSL : 0-31 0-31 0-31 0-31
TS into WAN : NONE NONE NONE NONE
-------------------------------------------------------------------------------CO_09_CM>
4.6.5.10 <MASTER ON/OFF [N = 1..4]> Command
This command activates/deactivates the «MASTER» mode on the interface with the number N.
For single-channel modems, the command is used without the number of the SHDSL channel.
In a data transmission systems one device should be configured as a Master device,
while the other as a Slave device.
4.6.5.11 <AUTO ON/OFF> Command
This command This command activates the modem in CA mode. This means that all SHDSL
channels are set to “SLAVE” mode and getting most settings from SHDSL line.
4.6.5.12 <EXT ON/OFF [N = 1..4]> Command
This command activates/deactivates the standard and the extended G.SHDSL mode on the
interface with the number N.
The EXT ON feature needs a special LICENSE KEY that has to be ordered together
with the unit.
In extended mode higher data rates and line codes (PAM4, PAM8, PAM16, PAM32, PAM64,
PAM128) are available.
