FlexDSL ORION 3 - MACFILTER [LAN1-5] [ON;OFF]> Command

User Manual LTU Orion 3
120
4.6.5.76 <MACFILTER [LAN1-5] [ON/OFF]> Command
The <MACFILTER [LAN1-5] [ON/OFF]> command enables or disables MAC Filter option on
selected LAN interface.
CX_05_NET>MACFILTER 4 OFF
--------------------------------------------------------------------------------
New MAC Filter Configuration
--------------------------------------------------------------------------------
Port LAN1 LAN2 LAN3 LAN4 LAN5
Mode ON/FILTER ON/INDICATE ON/BLOCK OFF/BLOCK OFF/FILTER
White list
1 0090f5-3e7a0b 0090f5-bb7a0b 0090f5-bb7a0b 0090f5-bb7a0b ---
2 0090f5-bb7a0b 0090cc-3e7a0b 0090cc-3e7a0b 0090cc-3e7a0b ---
3 0090cc-3e7a0b --- --- --- ---
4 0090f5-3e7fac --- --- --- ---
5 --- --- --- --- ---
6 --- --- --- --- ---
7 --- --- --- --- ---
8 --- --- --- --- ---
9 --- --- --- --- ---
10 --- --- --- --- ---
--------------------------------------------------------------------------------
It is allowed to use interface number or interface name, for example LAN1 as [IF] parameter.
4.6.5.77 <MACRULE [LAN1-5] [RULE]> Command
The <MACRULE [LAN1-5] [rule]> command changes MAC Filter [RULE] for selected interface:
CX_05_NET>MACRULE 4 INDICATE
--------------------------------------------------------------------------------
New MAC Filter Configuration
--------------------------------------------------------------------------------
Port LAN1 LAN2 LAN3 LAN4 LAN5
Mode ON/FILTER ON/INDICATE ON/BLOCK OFF/INDICATE OFF/FILTER
White list
1 0090f5-3e7a0b 0090f5-bb7a0b 0090f5-bb7a0b 0090f5-bb7a0b ---
2 0090f5-bb7a0b 0090cc-3e7a0b 0090cc-3e7a0b 0090cc-3e7a0b ---
3 0090cc-3e7a0b --- --- --- ---
4 0090f5-3e7fac --- --- --- ---
5 --- --- --- --- ---
6 --- --- --- --- ---
7 --- --- --- --- ---
8 --- --- --- --- ---
9 --- --- --- --- ---
10 --- --- --- --- ---
--------------------------------------------------------------------------------
It is allowed to use interface number or interface name, for example LAN1 as [IF] parameter.
MACRULE parameter
Parameter
Description
FILTER
Default rule. Unlisted MAC will be filtered.
INDICATE
Equal to Filter Rule, but the SNMP message will be generated.
Extended Traps must be activated.
BLOCK
If unlisted MAC will arrive the Port will be blocked and the SNMP
message will be generated.
Type ETHSD 10H/10F/100H/100F/AUTO X to restore port back.
4.6.5.78 <DOT1X [LAN1-5] {OPTION}> Command
The <DOT1X> Command configures IEEE 802.1x access control option on selected LAN
interface.
Syntax:
