FlexDSL ORION 3 - NM> & <LINKNM> Command

User Manual LTU Orion 3
72
-------------------------------------------------------------------------------
CX_06_FMM>
4.6.4.2 <NM> & <LINKNM> Command
The <NM> command displays the ITU-T G.991.2 Noise Margin. It means the maximum possible
increase in the Noise Margin for which the BER is expected to be not less than 10
-7
[dB].
CO_FMM>NM
Channel: DSL1 DSL2 DSL3 DSL4
SHDSL NM: 10.5 11.5 10.5 10.0 dB
The number of columns is equal to the number of SHDSL channels of the device.
The <LINKNM> command displays the noise margin of a complete link (CO, RR and CP).
A normal quality of a SHDSL data transmission is possible for NM ≥ 6 dB.
4.6.4.3 <STATUS> Command
The <STATUS> command displays the actual status of the SHDSL transceiver.
CO_01_FMM>STATUS
----------------------------------------------------------------------------
Status : DSL1 DSL2 DSL3 DSL4
----------------------------------------------------------------------------
I/F mode : CO CO CO CO
SYNC : - - - -
SEGD : - - - -
Power backoff : 0.0 0.0 0.0 0.0 dbm
Far end power backoff : 0.0 0.0 0.0 0.0 dbm
Loop attenuation : 0.0 0.0 0.0 0.0 dB
NMR : 0.0 0.0 0.0 0.0 dB
Bitrate : 0 0 0 0 kbit/s
SRU # : 0 0 0 0
Active sync. source : Internal Internal Internal Internal
Remote power state : 120V,ON OFF 120V,ON OFF
----------------------------------------------------------------------------
Temperature : 42.875 C
----------------------------------------------------------------------------
Option: T – update the table continuously.
Option: L – show the DSL and Link parameters. For the STATUS L explanation please see the
CONFIG command explanations.
Parameter
Value
Description
I/F mode
CO
CP
The interface is in the Master mode
The interface is in the Slave mode
SYNC
1
- (0)
Synchronization in the SHDSL line is established
Synchronization in the SHDSL line is absent
SEGD
1
0
-
Transmitted data over the SHDSL line are valid
Transmitted data over the SHDSL line are not valid
Data are not received
Power backoff
N
Output signal power [dBm]
Far end power backoff
N
Output signal power [dBm] remote side
Loop attenuation
N
Attenuation in the loop [dB]
NMR
N
Maximum possible increase in the noise margin for which the
BER is expected to be not less than 10
-7
[dB]
Bitrate
N
Data transmission rate of the SHDSL line [kbit/s]
SRU #
N
Number of regenerators in the system
