FlexDSL ORION 3 - BASERATE K;AUTO [N=1..4]> Command

User Manual LTU Orion 3
96
PAM 16
PAM 16
1
119
PAM 32
PAM 32
1
159
PAM 64
PAM 64
2
199
PAM 128
PAM 128
4
238
4.6.5.13 <BASERATE K/AUTO [N=1..4]> Command
This command sets the transmission rate K to the line SHDSL interface, where N is the number
of the SHDSL interface. For modems with just one SHDSL channel, the command is entered
without typing the number N. The data transmission is BASERATE * 64kbit/s.
For PAM16 the available rates (BASERATE) are the range from 3 to 60, and for PAM32 from 12
to 89.
Coding Type
Parameter
Values
Description
PAM16
N
3..60
Transmission rate over the line interface (N*64+8) kbit/s.
PAM32
12..89
Table 4.5 Available rates (BASERATE) for different coding types
WARNING
FOR LOW BASERATES YOU SHOULD USE THE LOWEST POSSIBLE
NUMBER OF CODE LEVELS. FOR A STANDARD BASED DEVICE USE
PAM16 AND NOT PAM32.
On the Slave device, the <BASERATE AUTO> command adapts the rate of the Slave device to
the rate of the Master device. In this case, PAM and Annex are automatically detected (opposite
Annex in the <CONFIG> configuration AB appears, opposite PAM is Auto). The command does
not change the Annex and PAM modes in the configuration. In the Slave mode, the <BASERATE
AUTO> command automatically detects all configurations.
4.6.5.14 <PAM [16/32] [N]> or <PAM [4-128] [N]> Command
This command sets the number of levels in the line code. The following options are possible –
4,8,16, 32, 64 & 128 for EXT mode ON. For modems with just one SHDSL channel, the command
is entered without typing the number N
CO_01_CM>PAM 16
4.6.5.15 <PAYLOAD list/NONE [N=1..4]> Command
This command sets the list of streams transmitted over the SHDSL channel. N is the number of
the SHDSL channel. The parameter list displays the list of E1, V.35 (Nx64), G.703/E0 and WAN
interfaces (Ethernet), separated by comma. The E1 interface may be denoted both by a short-
form (for example E1-1, E11), and by numbers (for example 1). Spaces in the list are not allowed.
The parameter NONE deactivates transmission of E1 and WAN over this SHDSL interface. For
modems with just one SHDSL channel, the command is entered without typing the number N
CO_CM>PAYLOAD V35,WAN
CO_CM>PAYLOAD E11,WAN
CO_CM>PAYLOAD G703,WAN 1
CO_CM>PAYLOAD NONE
