4.6.4.38 <SD SAVE [N=0..9]> Command
The <SD SAVE> command generates a configuration file and saves it to the SD card. The SD
SAVE <CR> generates the STARTUP.CFG file while SD SAVE x<CR> generates the desired
PROFILEx.CFG file. This cmd is only available if the SD card is inserted.
4.6.4.39 <SD LOAD [N=0..9]> Command
The <SD LOAD> command downloads the configuration file from the SD card to the unit. The
<SD LOAD> selects the STARTUP.CFG file while <SD LOAD x> selects the desired
PROFILEx.CFG file.
4.6.4.40 <SD BOOT [ON/OFF]> Command
The <SD BOOT> command enables/disables the automatically SD card Software Upgrade
feature during the boot sequence. If this feature is activated (SD BOOT ON) the software will
compare the SNAPSHOT.DAT, APP.BIN, LDR_xTU.BIN and STARTUP.CFG files with the
software and configuration files from the unit during the boot sequence. If any differences will be
detected the corresponding software / configuration file from the SD card will be downloaded to
the unit.
4.6.4.41 <SD STATUS> Command
The <SD status> command shows if the SD BOOT is enabled and the SD card information
CO_01_FMM>SD STATUS
SD Boot : OFF
Card type : SDHC
Capacity : 3781M
Blocks : 7744512
Read err : 0
Write err : 0
FAT : FAT32
Partition size : 3768M
Free space : 3766M
Snapshot files
/APP.BIN, correct
/LDR_LTU.BIN, correct
/STARTUP.CFG, correct
CO_01_FMM>
Status of every file that is checked during the boot sequence in case
<BOOT ON> is activated. Correct indicates that the actual software /
configuration file from the unit is equal to the file on the SD card.
4.6.4.42 <BERT> Command
The <BERT> command allows to enter into the submenu for BERT settings. Please also read the
description in the chapter “TECHNICAL DESCRIPTION / 3.2.5 BERT Test”.
