User Manual LTU Orion 3
115
RSTP configurations for whole device
PB
Port Base VLAN letter. Could be from A to E
Status
RSTP status for an instance.
VLAN/VID
Displays service VLAN number and VID for RSTP service messages
Prio
RSTP bridge priority
Hello
Hello time in seconds
FwdDelay
Forwarding Delay
MaxAge
Maximal Age
RSTP configuration for an interface
IFACE
Interface name
Prio
Interface priority
PathCost
Interface Path Cost
Edge
Port Edge behaviour:
Yes: means port can become “Edge”
No: means port will never be “Edge”
4.6.5.65 <RSTP STATE> Command
Command shows RSTP actual status.
CX_03_NET>RSTP STATE
PV PortID IFACE Status State Role Bitrate PCost Edge
-----------------------------------------------------------------
A 8001 LAN1 UP Fwd Desi 100.0Mbit AUTO/200000 Yes
8002 LAN2 DOWN --- --- --- AUTO/ --- ---
8003 LAN3 DOWN --- --- --- AUTO/ --- ---
8004 LAN4 DOWN --- --- --- AUTO/ --- ---
8005 LAN5 DOWN --- --- --- AUTO/ --- ---
8006 WAN1 UP Disc Alt 5.696Mbit AUTO/3511235 No
8007 R WAN2 UP Fwd Root 5.696Mbit AUTO/3511235 No
8008 WAN3 DOWN --- --- --- AUTO/ --- ---
8009 WAN4 DOWN --- --- --- AUTO/ --- ---
800A MWAN1 DOWN --- --- --- AUTO/ --- ---
800B MWAN2 DOWN --- --- --- AUTO/ --- ---
B 8001 MWAN1 DOWN --- --- --- AUTO/ --- ---
8002 MWAN2 DOWN --- --- --- AUTO/ --- ---
C 8001 MWAN1 DOWN --- --- --- AUTO/ --- ---
8002 MWAN2 DOWN --- --- --- AUTO/ --- ---
D 8001 MWAN1 DOWN --- --- --- AUTO/ --- ---
8002 MWAN2 DOWN --- --- --- AUTO/ --- ---
E 8001 MWAN1 DOWN --- --- --- AUTO/ --- ---
8002 MWAN2 DOWN --- --- --- AUTO/ --- ---
-----------------------------------------------------------------
CX_03_NET>
RSTP Status
PV
Port Base VLAN letter
PortID
Port identification
IFACE
Interface name
Status
Status of a port: Up or Down
State
State of a port: Forwarding or Discarding
Role
Port role: Designating, Root or Alternative
Bitrate
Port bitrate
PCost
Actual interface Path Cost.
Edge
Actual Edge status of a port.
Yes: means that port is “Edge” and switches own phases fast
No: means that port is “Non-edge” and participates in spanning tree
construction.
