User Manual LTU Orion 3
41
:SNMP
All commands
from VIEW +
SNMP
configuration
TRAPIP
COMMUNITY
SNMPSET
SNMPACL
RMONALARM
RMONEVENT
APPLY
CONFIRM
:NET
All commands
from VIEW + IP
configuration
SETIP
GATEWAY
NETMASK
MTU
SYSLOG
SNTP
APPLY
CONFIRM
PING
NOTE: The abridgements in braces “[ ]” can be entered instead of complete name.
If group has been entered without subgroup definitions, all subgroups will become available.
To define subgroup, type it after group name with “:” in the beginning of a subgroup.
The WEB interface will follow the rights of CLI interface.
In the RADIUS Server configuration example three different users have been defined in the users
file.
User ORION3ADMIN has full access to the device, because <Vendor-Specific> or <FlexDSL-
Rights> field is set to ALL.
ORION3USER has partial access, because <Vendor-Specific> or <FlexDSL-Rights> filed is set
to CONTROL + TEST + STATUS + CONFIG.
ORION3OPERATOR can only perform tests and check device status, because <Vendor-
Specific> or <FlexDSL-Rights> field is set to TEST + STATUS.
3.2.2.10 LLDP
LLDP is an abbreviation of Link layer discovery protocol defined in IEEE 802.1AB. The LLDP
protocol is used by network devices to identify themselves and to advertise their capabilities to
their peers over IEEE 802 (Ethernet) networks or over WAN (MWAN) channels formed via
DSL/E1 links. LLDP protocol is vendor neutral, so various devices can interoperate and introduce
their capabilities to remote peers even if they were produced by other vendors. The LLDP
implementation in FlexDSL Orion3 / MiniFlex devices can read and display the following
parameters received from remote peer:
Parameter
Value
Description
Chassis ID
String
Manually assigned chassis ID or an chassis MAC address
Port ID
String
Remote port ID
TTL
Timer
Time To Live Value in seconds shows the validity of remote
system information
Port Description
String
Manually assigned port description
System Description
String
Manually assigned system description
System Capabilities:
Digit
Capabilities of remote system (Bridge, Router, Phone, etc.)
Management address:
IP Address
Management IP address of remote system
Management VID:
VLAN ID
A VLAN ID assigned for management port
Maximal Frame Size
Digit
Maximal size of frame in bytes the remote system can accept
MED capabilities
Array
Shows if the remote peer is Endpoint or Network Connectivity
Device and its Media Endpoint Device capabilities
Hardware Revision
String
Remote system hardware version
Software Revision
String
Remote system software version
Serial Number
String
Remote system serial number
Model Name
String
Remote system model name
