User Manual LTU Orion 3
118
There are 8 separately managed VLANs in the modem. For each managed VLAN the VID (VLAN
ID) can be selected with the VID command.
4.6.5.70 <QOS [IF] [0..7]> Command
This command sets default QoS for interfaces in ACCESS or MIXED mode ([IF] is LANx, INT).
The Lowest priority is 0, the highest is 7. Default QoS is used to assign quality of service
information for ingressing untagged traffic.
The INT interface is always considered in ACCESS mode and all frames coming from the INT
interface will have default QoS assigned.
4.6.5.71 <ALLOW [IF] [VLAN list]> Command
This command selects which VLANs are allowed on interfaces in TRUNK or MIXED mode ([IF] is
LANx, WANx).
The VLAN list is a comma-separated list of allowed VLANS from 1 to 8, and the word OTHER
(allows all other VLANs except 1-8). Spaces in the list are not allowed. To allow all VLANS on the
interface, write ALL in the list.
CP_01_NET>ALLOW LAN1 1,2,3
CP_01_NET>ALLOW WAN2 5,3,OTHER
CP_01_NET>ALLOW WAN4 ALL
4.6.5.72 <VID [1-8] ID> Command
The <VID [1...8] ID> command sets VID for the VLAN with the number 1..8 equal to the ID
parameter. ID=1...4094. 8 VLANs are supported by the device, and available VID numbers
assigned to the VLAN are in the range from 1 to 4094. VID as well as QoS are an attribute of the
VLAN packet.
4.6.5.73 <MACLIST SHOW> Command
Without parameters the <MACLIST SHOW> command displays the whole MAC Filter table for all
available interfaces:
CX_05_NET>MACLIST SHOW
--------------------------------------------------------------------------------
Running MAC Filter Configuration
--------------------------------------------------------------------------------
Port LAN1 LAN2 LAN3 LAN4 LAN5
Mode ON/FILTER ON/INDICATE ON/BLOCK ON/BLOCK OFF/FILTER
White list
1 0090f5-3e7a0b 0090f5-bb7a0b 0090f5-bb7a0b 0090f5-bb7a0b ---
2 0090f5-bb7a0b 0090cc-3e7a0b 0090cc-3e7a0b 0090cc-3e7a0b ---
3 0090cc-3e7a0b --- --- --- ---
4 --- --- --- --- ---
5 --- --- --- --- ---
6 --- --- --- --- ---
7 --- --- --- --- ---
8 --- --- --- --- ---
9 --- --- --- --- ---
10 --- --- --- --- ---
--------------------------------------------------------------------------------
Port identifier of the internal Ethernet switch
ON: MACFILTER is enabled
OFF: MACFILTER is disabled
FILTER: non-listed ingress packets will be filtered
INDICATE: non-listed ingress packets will be filtered and SNMP Trap
will be generated
