FlexDSL ORION 3 - ENCODE [NRSB]> Command

User Manual LTU Orion 3
89
PTMP [ADD|DEL] [IF] Add/delete interface to PTMP network
PTMP SHOW Show interfaces of PTMP network
MODE [N] Switches number of DSL channels to N
LICENSE Show active licenses
LICENSE ADD [key] Add software options
NET Network configuration menu
APPLY [ALL/GROUP] Apply changes to running configuration
CONNECT [N:[1-13/R]] Establish connection to remote unit
LINK [NN] Establish local connection
LINKCLEAR Exit all local connections
M Return to Main Menu
H Show available commands
-------------------------------------------------------------------------------
CO_01_CM>
4.6.5.2 <ENCODE [NRSB]> Command
This command shows encoding configuration.
CO_01_CM>ENCODE
Running configuration
--------------------------------------------------------------------------------
Encoding : WAN1 WAN2 WAN3 WAN4
--------------------------------------------------------------------------------
Destination : DSL1 DSL2 DSL3 DSL4
Key : set set set set
Enabled : no no no no
--------------------------------------------------------------------------------
CO_01_CM>
Optional parameters describe what configuration must be shown: New, Running, Startup,
Backup.
4.6.5.3 <ENCODE KEY [N]> Command
This command enters pre-shared secret Key for selected WAN channel [N]:
CP_CM>ENCODE KEY 1
Please enter encryption key [mykey1]:
Please repeat encryption key:
--------------------------------------------------------------------------------
Encoding : WAN1 WAN2 WAN3 WAN4
--------------------------------------------------------------------------------
Destination : DSL1 DSL2 DSL3 DSL4
Key : set set set set
Enabled : yes yes yes yes
--------------------------------------------------------------------------------
Warning: New Encoding configuration is shown, because it differs from running.
To view new encoding configuration, type 'ENCODE N'.
To view running encoding configuration, type 'ENCODE R'.
To apply changes in configuration, type 'APPLY'.
Do not forget to 'CONFIRM' a good working configuration.
CP_CM>
The pre-shared Key must contain only the following characters: ! " # $ % & ' ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9
: ; < = > ? @ A B C D E F G H I J K L M N O P Q R S T U V W X Y Z [ \ ] _ ` a b c d e f g h i j k l m n o p q
r s t u v w x y z { | } ~. Spaces will be truncated.
NOTE: Pre-shared Key can be unique for every channel or common. For unique keys
please be sure that keys on both sides of WAN channels match.
Definitions
Encoding
Name of WAN channel
Destination
The physical channel that carries logical WAN channel. It can be either DSL or E1.
Key
Tells if Key has been entered or not.
Enabled
Shows if encoding is enabled or disabled on this channel.
