4.6.3.11 <LINKALARM> Command
This command shows the actual alarm status for all units connected over SHDSL.
-----------------------------------------------------------------------------
Local Alarm: Major
-----------------------------------------------------------------------------
DSL 1 DSL 2
-----------------------------------------------------------------------------
RR01 Major
CO Major
-----------------------------------------------------------------------------
CO_PM>CO_PM>
4.6.3.12 <ALARMLOG [N]> Command
This command displays the alarm log (list of all alarms that were detected) for the specified
SHDSL interface.
-----------------------------------------------------------------------------
Time ago | Unit | Event | Description
-----------------------------------------------------------------------------
04:45s | LOCAL | E1-2 | LOS-S ----- BER-S ----- -----
04:18s | RR 1 | N-SIDE | LOS ----- ----- ----- ----- LOOP2 ------
04:16s | CO | E1-1 | ----- ----- ----- ----- -----
-----------------------------------------------------------------------------
CO_PM>
Option: С – clears the Alarm log
Time ago - Time since the alarm was detected.
Unit - Unit in link, that reported about the alarm.
Event - Interface of the unit, that detected the alarm.
4.6.3.13 <LINKDIAG> Command
The <LINKDIAG> command displays important parameters of DSL link for local unit, remote unit
and for connected repeaters.
CO_06_FMM>LINKDIAG
Querying link data: DSL1(.) DSL3(.)
--------------------------------------------------------------------------------
DSL Unit NM G.826(ES) Status Alarms Description
--------------------------------------------------------------------------------
1 local (CO) 19.0 000000001 up None DSL1
RR1-N 18.0 000000000 up None DSL2
RR1-C 18.0 000000001 up DSL1
remote(CP) 18.0 000000000 up Minor DSL1
--------------------------------------------------------------------------------
2 local (CO) ---.- 000000000 pre act LOSW DSL2
--------------------------------------------------------------------------------
3 local (CO) 18.0 000000001 up None DSL3
RR1-N 19.0 000000000 up None DSL4
RR1-C 18.0 000000001 up DSL3
remote(CP) 17.0 000000000 up Minor DSL2
--------------------------------------------------------------------------------
4 local (CO) ---.- 000000000 pre act LOSW DSL4
--------------------------------------------------------------------------------
CO_06_FMM>
Parameter
Value
Description
DSL
1 ... 4
Number of DSL channel counted on local unit
Unit
local
remote
RRx-N
RRx-C
The unit on which the LINKDIAG command executed
Remote unit
"N" and "C" side of Repeater with number x. X always counted
from the Master side. "N" side is connected to Master, while "C"
side is connected to Slave
