User Manual LTU Orion 3
78
The command MACTABLE OTHER shows the entries for OTHER VLANs (with VID not matching
one of VLAN 1..8.
First column is the MAC address. The second column is the originating interface where this MAC
is learned from. Third column is VLAN number. Forth column indicates if MAC address is blocked.
CX_05_FMM>MACTABLE
00:0f:d9:10:45:84 MWAN1 VLAN1
00:0f:d9:06:83:20 MWAN2 VLAN1
00:e0:4c:69:23:41 MWAN2 VLAN1
00:0f:d9:05:3f:8d MWAN1 VLAN1
00:0f:d9:06:77:91 INT VLAN1
00:0f:d9:04:d3:95 MWAN1 VLAN1
00:0f:d9:10:21:77 MWAN1 VLAN1
00:90:f5:3e:7a:0b VLAN1 BLOCKED
CX_05_FMM>
4.6.4.15 <LLDP STAT [IF/ALL]>
The <LLDP STAT [IF/ALL]> command shows detailed LLDP status for selected port or for all
ports.
CX_06_FMM>LLDP STAT ALL
IfIndex 11 neighbors
00:0f:d9:05:5e:61 age: 1 ttl: 121
Chassis ID: MAC address 00:0f:d9:05:5e:61
Port ID: Interface name MWAN2
TTL: 121
Port description: MWAN2
System description: FG-PAM-SA4N-2Eth, V84 LABOR (SW: 1.6.17 HW: 1.4)
System capabilities: system: 0x4 enabled: 0x4
Management address: IPv4 192.168.1.26 ifIndex(2): 5
Management VID: 1
Maximum frame size: 2048
MED capabilities: device type: 1, capabilities: 0x21
Hardware Revision: 1.4
Software Revision: 1.6.17
Serial Number: CCS110412309
Model Name: FG-PAM-SA4N-2Eth, V84 LABOR
CX_06_FMM>
Parameter
Value
Description
Chassis ID
ID
MAC address or ID of remote unit
Port ID
ID
Remote port identification
TTL
Integer
Remote table actualization time in seconds
Port description
String
Remote port description
System Description
String
System name
System Capabilities
HEX
System capabilities according to IEEE 802.1AB
Management Address
IP Address
IP address of remote unit
Maximum frame size
Integer
Maximal frame size the unit can accept. Note it reflects only
the LAN switch side of the modem. Maximal Frame size is
2044 for data transmission over DSL
MED Capabilities
HEX
System capabilities according to MED extension
Hardware Revision
String
Hardware version
Software Revision
String
Software version
Serial Number
String
System serial number
Model Name
String
Remote system name
